The most universal charger – one charger for all rechargeable batteries!
- one charger, widest compatibility
- 5 operating modes: charging, discharging, refreshing, test (grad.), storage mode
- compatible with lithium-ion batteries 1.5 V and 3.6/3.7 V, LiFePO4 3.2 V and Ni-MH 1.2 V
- intelligent battery recognition, no risk of incorrect charging
- actual capacity measurement (from discharge) also for 1.5V batteries
- two charging modes: standard and LifePO4
- quick stop after full charge, guarantees battery life and performance
- a range of protections
Key features:
- independent channels
- supports up to 4 types of batteries
- compatible with over 30 battery sizes
- high precision charging termination
- adjustable charging current
- fast charging (up to 3A)
- battery capacity test
- storage mode
- refreshing Ni-MH batteries
- discharge mode
- internal resistance measurement
- reactivation of low voltage cells
- mode memory retention
- high
Wide Compatibility
Supports a wide range of chemistry types and battery sizes, with an adjustable socket length from small 10440 to long, protected 21700 — ensuring a precise fit. The VX2 Pro will handle virtually any battery available on the market that has a length from 34mm to 80mm.
Greatest compatibility in Xtara chargers so far! Supports batteries:
3.6/3.7 Li-ion /IMR/INR/ICR and 3.2V Li-FePO4 in sizes:
- 10440 / 14500 / 14650 / 16340 / 17335 / 17500 / 17670 / 18350 / 18490 / 18500 / 18650 / 18700 / 20700 / 21700 / 22650 / 25500 / 26650 / 32650
1.5V Li-ion in sizes:
- AAA / AA
1.2V Ni-MH in sizes:
- AAA / AA / A / SC / C / D
2 independent charging channels - independent operating modes
Fully independent channels that allow individual setting of a specific operating mode for each battery.
For example, you can refresh an old Ni-MH battery on one channel while testing the capacity of a 21700 battery on the other.
Professional features - simple operation
VX2 Pro is a multifunctional smart charger designed for users who need more than just charging — without unnecessary complexity. Whether you are a hobbyist, technician, or advanced user, it provides comprehensive battery management that is easy to use yet very precise.
The charger offers up to 5 modes:
- charging
- capacity measurement (Grad.)
- storage mode (Storage)
- refreshing (refresh)
- discharging
Smart charging to maximize battery lifespan
Intelligently detects battery types and automatically selects the optimal charging method, then automatically adjusts the best charging current based on the adapter power and battery condition.
3-stage method for charging Li-ion batteries: TC/CC/CV
- Phase TC: cells discharged below 2.75V are 'woken up' with a lower current.
- Phase CC: after reaching 2.75V, the cell is charged with the target charging current
- Phase CV: when the cell is almost fully charged, the charger switches to charging with a decreasing current until the voltage of 4.2V is reached on the cell. After reaching 4.2V
Charging batteries using the CVSA method
- charging batteries while maintaining a lower temperature
- multiple protections to avoid undercharging and overcharging. Over-voltage protection, time limit protection, and -delta V detection, ensuring a safer and more efficient charging process.
Optional 0.25 A/0.5 A/1 A/2 A/3 A
Allows manual adjustment of the current according to the user's needs.
* The charging current for Ni-MH and lithium-ion batteries 1.5 V is constant and amounts to 0.5 A.
Grad – discover the actual capacity of your battery. This feature is ideal for:
➤ verifying the manufacturer's claims
➤ detecting worn or damaged batteries
➤ matching cells in multi-battery configurations
* When testing the capacity of a 1.5 V lithium-ion battery, the voltage is not displayed. The volume in mWh of the 1.5 V lithium-ion battery is the output energy after accounting for conversion losses.
Smarter storage for battery protection
VX2 Pro is the first charger to support the storage function for 1.5 V lithium-ion batteries — intelligently adjusting the cells to optimal voltage to reduce self-discharge, slow aging, and extend battery life.
Refreshing – revive old Ni-MH batteries
The capacity and performance of Ni-MH batteries decrease over time. The refreshing function helps them achieve the maximum possible capacity.
➤ Suitable for older or frequently used batteries. It intelligently adjusts discharge and charge cycles based on the battery's condition.
* For Ni-MH batteries only, other batteries will be automatically charged under this function.
Discharging the battery to the cut-off voltage for quick capacity checking and optimal maintenance.
* After the discharging process is complete, set the
charging function to prevent excessive battery discharge.
Internal Resistance Measurement
Displays the internal resistance of each cell — providing deeper insight into the state of the battery. A very useful feature when using batteries in devices with high current draw. Resistance measurement is also helpful in situations where the device uses multiple batteries simultaneously.
Reactivation of low voltage batteries
The low current activation introduced by XTAR allows for a safe and effective way to revive excessively discharged cells.
USB-C Input with Fast Charging Function
Memory after power off
The VX2 Pro retains mode and function settings after a power interruption until they are changed.
The VX2 Pro charger intelligently remembers the LiFePO4 mode settings. Even after a power interruption or accidental disconnection, it automatically returns to the LiFePO4 mode upon power restoration, eliminating the risk of applying inappropriate charging parameters that could damage valuable LiFePO4 batteries.
Full View Display Panel
Large HTN LCD display panel, all information visible. Each socket shows voltage, current, capacity, and charging status. Simple layout, easy to read.
- Li-ion batteries 3.6-3.7V, protected (with PCM/PCB)
- LiFePO4 batteries
- Protected Li-ion 1.5V batteries
- Ni-MH Batteries
- 5V/2A, 9V/2A, 12V/2A(Zalecane PD20W)
- Processor-controlled TC/CC/CV for Li-ion
- Processor-controlled CC with -ΔV/0ΔV/PVD for Ni-MH
- Reactivation of deeply discharged cells and 0V cells
- Measurement of the capacity of Li-ion batteries 1.5V
- Before overload / short circuit
- Before reverse polarity of the cells
- Before overcharging
- Timer switch
- Detection of damaged and alkaline cells
- Charging (Charge)
- Grade: charging -> discharging -> charging
- Capacity measurement in mAh (Test)
- Refreshing / Conditioning (Refresh/Cycle)
- Discharge
- VX2 Pro Charger
- USB cable
- Power supply
- Drawstring pouch
- Li-ion batteries 3.6-3.7V, protected (with PCM/PCB)
- LiFePO4 batteries
- Protected Li-ion 1.5V batteries
- Ni-MH Batteries
- 5V/2A, 9V/2A, 12V/2A(Zalecane PD20W)
- Processor-controlled TC/CC/CV for Li-ion
- Processor-controlled CC with -ΔV/0ΔV/PVD for Ni-MH
- Reactivation of deeply discharged cells and 0V cells
- Measurement of the capacity of Li-ion batteries 1.5V
- Before overload / short circuit
- Before reverse polarity of the cells
- Before overcharging
- Timer switch
- Detection of damaged and alkaline cells
- Charging (Charge)
- Grade: charging -> discharging -> charging
- Capacity measurement in mAh (Test)
- Refreshing / Conditioning (Refresh/Cycle)
- Discharge
- VX2 Pro Charger
- USB cable
- Power supply
- Drawstring pouch
